P215D BMW Fault Code

Description:

Variable Cam Timing Over-advanced (Bank 1) The comprehensive component monitor (CCM) monitors the VCT position for an over-advanced camshaft timing.
The test fails when the camshaft timing exceeds a maximum calibrated value or remains in an advanced position.

BMW cam timing improperly set No oil flow to the VCT piston chamber Low oil pressure VCT solenoid valve stuck closed Camshaft advance mechanism binding (VCT unit) P215D DTC is a check of the VCT unit.

P215D Code Symptoms :

OBD P215D code and tailpipe testing are two different approaches to identify vehicles in need of repair. The OBD system looks for broken or malfunctioning emissions control components and P215D, while tailpipe tests sample a vehicle's exhaust to see if it is above or below certain prescribed limits. Given the robust nature of today's emissions control components, it is entirely possible for an individual component to malfunction without leading to an immediate increase in emissions at the tailpipe.

In such cases, other components (like the catalyst) can temporarily compensate for the part that is broken however, these other components can only do double duty for so long before they, too, begin to malfunction. In addition, OBD also monitors for and other malfunctions in the fuel system problems that traditional tailpipe tests were not designed to identify. Most state and local areas also include a gas cap pressure test as part of an emission inspection.

Diagnosis And Repairing P215D

P215D OBD2 reports a sensor fault, replacement of the sensor is unlikely to resolve the underlying problem. The fault is most likely to be caused by the systems that the sensor is monitoring, but might even be caused by the wiring to the sensor itself.

How to fix P215D code ?

• Erratic camshaft position due to low oil pressure
• Faulty ignition coil (s)
• Faulty Air fuel ratio (A/F) Sensor 1 Bank 1
• Variable Camshaft Timing (VCT) position circuit is open or shorted

At this point we are assuming that the fuses and relays are good. You will need to locate the PCM/TCM and the power input signal circuit using your vehicle information source.

Unplug the connector from the PCM/TCM, place the ignition switch in the ON position, and probe the appropriate circuit with the positive test lead of the DVOM.
